Frontal Segmentation

POST /frontal-segmentation

Segments dental structures in frontal intra-oral images and evaluates occlusal conditions using orthodontic evaluation standards.

Image Type: Frontal Intra-oral Photographs

Tags: Segmentation Frontal View ICON

Request Parameters

Parameter	Type	Required	Description
PatientID	string	✅	Unique patient identifier
TimeStamp	string	✅	Analysis session timestamp
ImageName	string	✅	Full URL to the image
StandardName	string	❌	Evaluation standard (default: "ICON")
PlotLabels	boolean	❌	Plot classification labels on output

Example Request

curl -X POST \
  https://api.annie-insights.com/api/v2/frontal-segmentation \
  -H "Content-Type: application/json" \
  -H "x-api-key: YOUR_API_KEY" \
  -d '{
    "PatientID": "P-001",
    "TimeStamp": "2026-05-24",
    "ImageName": "https://example.com/frontal.jpg",
    "StandardName": "ICON",
    "PlotLabels": true
  }'

Sample Response

{
  "Version": "2024.1.0",
  "PatientID": "P-001",
  "TimeStamp": "2026-05-24",
  "ImageName": "a1b2c3d4_frontal.jpg",
  "Results": {
    "i1_rgt_up": {"missing": false, "points": [[441,195],[441,201],"..."]},
    "m2_rgt_up": {"missing": false, "points": [[916,227],[919,225],"..."]},
    "m3_rgt_up": {"missing": true, "points": [0,0]}
  },
  "OutputImageUrl": "https://annieapistorage.blob.core.windows.net/..."
}
