Frontal Cephalometric Landmarks

POST /ceph-frontal-points

Detects 118 cephalometric landmarks on frontal (PA) cephalometric X-ray images for craniofacial evaluation.

Image Type: Frontal (PA) Cephalometric Radiograph | Tags: 118 Landmarks Frontal Ceph X-ray AI

Request Parameters

Parameter	Type	Required	Description
PatientID	string	✅	Unique patient identifier
TimeStamp	string	✅	Analysis session timestamp
ImageName	string	✅	Full URL to the image

Example Request

curl -X POST \
  https://api.annie-insights.com/api/v2/ceph-frontal-points \
  -H "Content-Type: application/json" \
  -H "x-api-key: YOUR_API_KEY" \
  -d '{"PatientID":"P-001","TimeStamp":"2026-05-24","ImageName":"https://example.com/frontal_ceph.jpg"}'

Sample Response

{
  "Version": "2024.1.0",
  "NumberOfPredictedPoints": 118,
  "Results": {
    "Front_58": {"x_coordinate": 669, "y_coordinate": 468},
    "Front_36": {"x_coordinate": 515, "y_coordinate": 422},
    "SasFront_14": {"x_coordinate": 778, "y_coordinate": 183}
  },
  "OutputImageUrl": "https://annieapistorage.blob.core.windows.net/..."
}
