Clinical Findings

POST /clinical-images

Detects clinical findings in dental photographs — decay, orthodontic indicators, restorations, periodontal conditions, and brackets using YOLO deep learning object detection.

Image Type: Intra-oral Photographs (Right, Front, Left, Upper, Lower)

Tags: Detection Intra-oral Photos AI

Request Parameters

Parameter	Type	Required	Description
PatientID	string	✅	Unique patient identifier
TimeStamp	string	✅	Analysis session timestamp
ImageName	string	✅	Full URL to the image

Example Request

curl -X POST \
  https://api.annie-insights.com/api/v2/clinical-images \
  -H "Content-Type: application/json" \
  -H "x-api-key: YOUR_API_KEY" \
  -d '{
    "PatientID": "P-001",
    "TimeStamp": "2026-05-24",
    "ImageName": "https://example.com/image.jpg"
  }'

Sample Response

{
  "Version": "2024.1.0",
  "PatientID": "P-001",
  "TimeStamp": "2026-05-24",
  "ImageName": "a1b2c3d4_clinical.jpg",
  "ImageContents": {
    "decay": 2,
    "restoration": 1
  },
  "Results": {
    "decay": [
      {"ClassName": "decay", "TopLeft": [120, 80], "BottomRight": [200, 160]},
      {"ClassName": "decay", "TopLeft": [450, 200], "BottomRight": [510, 260]}
    ],
    "restoration": [
      {"ClassName": "restoration", "TopLeft": [300, 90], "BottomRight": [380, 170]}
    ]
  },
  "OutputImageUrl": "https://annieapistorage.blob.core.windows.net/api-output-images/clinical-images/...?se=...&sp=r&sv=...&sr=b&sig=..."
}

tip

The OutputImageUrl is a time-limited Azure Blob SAS URL valid for 72 hours. See Output Images for details.
